后处理路径:
C:Documents and SettingsAll UsersDocumentsshared Mcamx6millPostsMPFAN.pst
用记事本打开方式打开,
搜素 Tooltable in header - with tool comments at T/C
如下:
tool_info : 3 #Output tooltable information?
#0 = Off - Do not output any tool comments or tooltable
#1 = Tool comments only
#2 = Tooltable in header - no tool comments at T/C
#3 = Tooltable in header - with tool comments at T/C
注意这里 tool_info : 3 必须要选择2或3才可以
解释如下:
刀具信息: 3 #输出刀具信息?
# 0 =——不输出任何评和刀具信息
# 1 =只更换工具时有评论
# 2 =只在 程序头处有工具评论,更换工具前没有评论
# 3 = 程序头处于更换工具时都有评论
快去小试试吧
示例程序如下:
O0001 (程序号)
(0000882R0-P1 WORK=G54) (程序备注)
(DATE=DD-MM-YY - 22-11-14 TIME=HH:MM - 10:22) (程序处理时间)
( T1 = 60.FM = H1 / XY=0. / Z=.1 ) (程序头处刀具信息)
( T2 = 8.0 ROU = H2 / WEAR COMP / DIA.=8. / XY=.2 / Z=0. )
( T3 = 6.6 BM = H3 / XY=0. / Z=.15 )
( T4 = 5.0 EM = H4 / XY=0. / Z=.2 )
( T5 = 6.0 NC = H5 / WEAR COMP / DIA.=6. )
( T6 = 2.7 DR = H6 )
( T7 = 3.0 BM = H7 )
( T8 = 8.0 EM = H8 / WEAR COMP / DIA.=8. )
G21
G0 G17 G40 G49 G80 G90
N1
( T1= 60.FM / H1 / DIA.=60. ) (更换刀具前刀具信息)
( XY=0. / Z=.1 ) (切削余量)
T1 M6 (更换刀具)
